How to Configure Port Security on Cisco Switches

In today’s interconnected business environments, network security is more critical than ever. One of the simplest yet most effective protections you can apply at the access layer of your network is Port Security.

On Cisco switches, Port Security restricts input to an interface by limiting and identifying MAC addresses of the devices that can connect. This helps prevent unauthorized devices from plugging into your network and accessing sensitive resources.

This article walks you through what port security is, why it matters, and how to configure it step by step.

What Is Port Security on Cisco Switches?

Port Security is a feature that allows administrators to:

• Restrict a port to specific MAC addresses
• Limit the number of devices that can connect to a port
• Decide what happens when a violation occurs (e.g., block the port, drop traffic, or alert administrators)

It is particularly useful for access layer ports that connect end-user devices, such as PCs, printers, or IP phones.

Key Benefits of Port Security

• Prevents unauthorized access by rejecting devices not on the trusted MAC list
• Mitigates MAC flooding attacks, which can overwhelm switch CAM tables
• Improves visibility and control over devices connecting to your network
• Enforces network policy at the edge

Port Security Concepts

Before diving into configuration, it’s important to understand the key terms:

• Secure MAC Address: A MAC address allowed on a port
• Maximum Addresses: The number of MAC addresses permitted per port
• Violation Modes: Determines the switch’s response to an unauthorized device

Violation Modes:

1. Protect – Drops traffic from unauthorized MAC addresses (no alert)
2. Restrict – Drops unauthorized traffic and generates a log/alert
3. Shutdown – Puts the port into error-disabled state (default mode)

Step-by-Step: Configuring Port Security

Here’s how to configure port security on a Cisco switch.

Step 1: Enter Interface Configuration Mode

Switch> enable
Switch# configure terminal
Switch(config)# interface fastEthernet 0/1

Step 2: Enable Port Security

Port security works only on access ports, not trunk ports.

Switch(config-if)# switchport mode access
Switch(config-if)# switchport port-security

Step 3: Set the Maximum Number of MAC Addresses

Switch(config-if)# switchport port-security maximum 2

This example allows only 2 devices on the port.

Step 4: Configure Allowed MAC Addresses

Option A: Statically Configure a MAC Address

Switch(config-if)# switchport port-security mac-address 0011.2233.4455

Option B: Sticky Learning (Dynamic to Static)

Switch(config-if)# switchport port-security mac-address sticky

Sticky mode learns MAC addresses dynamically and saves them as if they were manually configured.

Step 5: Configure Violation Action

Switch(config-if)# switchport port-security violation restrict

Options are:

• protect
• restrict
• shutdown (default)

Step 6: Verify Configuration

Switch# show port-security interface fastEthernet 0/1

This displays allowed addresses, violation mode, and current status.

Example: Full Configuration

Here’s a complete configuration for port FastEthernet 0/1:

Switch> enable
Switch# configure terminal
Switch(config)# interface fastEthernet 0/1
Switch(config-if)# switchport mode access
Switch(config-if)# switchport port-security
Switch(config-if)# switchport port-security maximum 2
Switch(config-if)# switchport port-security mac-address sticky
Switch(config-if)# switchport port-security violation restrict
Switch(config-if)# end
Switch# write memory

This configuration:

• Allows up to 2 MAC addresses
• Learns and saves them automatically
• Restricts unauthorized devices and logs violations

Troubleshooting Port Security

• Port goes into err-disabled mode:
  • The violation mode is likely set to shutdown. Use: Switch(config-if)# shutdown Switch(config-if)# no shutdown
• Check logs for violations: Switch# show log
• Reset port security counters: Switch# clear port-security all

Best Practices

• Apply port security only on end-user access ports
• Use sticky learning for environments with dynamic devices (e.g., laptops)
• Set reasonable maximum MAC addresses (usually 1 for desktops, 2 for VoIP phones + PC)
• Use restrict mode instead of shutdown in high-availability environments to avoid accidental downtime
• Monitor and log violations for auditing

Conclusion

Port security is a simple yet powerful way to secure Cisco switches at the access layer. By limiting the number of devices and controlling which MAC addresses can connect, you reduce risks from unauthorized access and attacks.

With the steps above, you can confidently configure port security, enforce network policy, and protect your organization from common security threats.
